1. Adopt high performance 1.3 inch 1.3MP CMOS.
2. Support dual stream compression technology.
3. Rotate 360 degrees in horizontal direction,driven by exact engine,operate stably with precise position-setting.
4. The rotation speed can be adjustable according to the zoom rate of camera lens, auto-focus, auto white balance.
5. Built-in OSD. Several control protocols are compatible and Baud rate is adjustable.
6. Vertical 90 degrees continuous monitoring after auto reversing 180 degrees.
7. Patrol track: 4 groups, each can record 200 actions.
8. Cruise track: Total 30 presets can join cruise, can setting the presets residence time.
9. Support Horizontal scan, deuce area scan, scan random.
10. Rotation speed: Horizontal & Vertical Min 0.01 degrees, Max 200 degrees / S.
11. Signal model: PAL/NTSC.
Specification:
|
General
|
| Performance |
Motion detection, Night Vision |
|
|
Network
|
| Protocol |
DDNS, UDP, SMTP, UPNP, DHCP, PPPOE, FTP, RTP, RTSP, HTTP, DNS, RTCP, TCP/IP, ONVIF |
|
|
System / Hardware
|
| Sensor Size |
1/3 inch Progressive Scan |
| Minimum Illumination |
Color: 0.1Lux, B/W: 0.01Lux |
|
|
Media Format
|
| Video Compression Format |
M-JPEG |
| Audio Compression Format |
G.726, G.711 |
| Video Bit rate |
CBR / VBR, 32Kbps-16Mbps |
|
|
Night Vision
|
| Infrared Distance |
120-150m |
|
|
Physical Environment
|
| Operate Temperature |
-20 to 50 Degree Celsius |
|
|
Package Include
|
| Package Contents |
1 x Camera
1 x Mounting Accessories
1 x CD
1 x Power Charger |
|
|
Package Weight
|
| One Package Weight |
2.95kgs / 6.50lb
|
| One Package Size |
28.5cm * 24.5cm * 19cm / 11.22inch * 9.65inch * 7.48inch
|
| Carton Weight |
19.60kgs / 43.21lb
|
| Carton Size |
51cm * 40cm * 59cm / 20.08inch * 15.75inch * 23.23inch
|
| Loading Container |
20GP: 221 cartons * 8 pcs = 1768 pcs
40HQ: 514 cartons * 8 pcs = 4112 pcs
|
|
